The TS45 series ultra-miniature SMT tact switch offers a 4.5mm x 4.5mm package size for your application design.
The TS45 series ultra-miniature SMT tact switch offers a 4.5mm x 4.5mm package size for your application design. It has a surface mount termination, two operating forces to choose from, and an operating life cycle up to 500,000. It also offers multiple actuator lengths from 3.8mm to 7.0mm.
A mini tact switch is a specialized electronic component designed for tactile input control with a side-mounted configuration, offering precise switching functionality in electronic devices. Let's explore the key features and benefits of a 3-pin side tact push button:
Key Features:
Side-Mounted Design: The tact switch button features a side-mounted configuration, allowing for convenient placement on circuit boards or control panels.
Tactile Feedback: This push button provides tactile feedback, giving users a physical response when actuated, ensuring accurate and responsive control.
Three-Pin Configuration: With three pins for connection, this push button offers versatile wiring options for integration into electronic circuits.
Benefits:
Space-Efficient: The side-mounted design of the tact switch smd optimizes space utilization on circuit boards, making it suitable for applications with limited board space.
Tactile Response: With tactile feedback, this push button enhances user experience by providing physical confirmation of switch actuation, reducing errors and improving usability.
Versatile Wiring: The three-pin configuration allows for flexible wiring options, enabling seamless integration into electronic designs with different connection requirements.
tactile tact push button switch offers precise tactile input control with a space-efficient and versatile design. Its side-mounted configuration, tactile feedback, and three-pin wiring configuration make it a valuable component for a wide range of electronic applications requiring reliable switching functionality with tactile confirmation.
The 3 Pin push button tact switch is a momentary contact switch that delivers a tactile response when pressed. Unlike traditional top-actuated tact switches, this model is activated from the side, making it ideal for applications where space or interface design calls for lateral actuation. The three-pin configuration is simple and efficient, offering stable PCB mounting and straightforward circuit integration.
Typically used on surface-mount or through-hole PCBs, the switch temporarily closes an electrical circuit when pressed, then opens again upon release. The built-in tactile mechanism provides a physical "click" feedback to the user, ensuring confident input even without visual confirmation.
1. Ultra-miniature 6.1 x 3.5mm
2. Multiple actuator options
3. Surface mount
4. Multiple operating force options
