Good quality, small barrel-type power socket for DC power supplies
A 3-pin DC power jack is a widely used component in electronics, providing a secure and consistent means of delivering direct current (DC) power from an external source to an electronic device. Unlike the standard 2-pin DC jacks, the 3-pin version offers added functionality—especially in terms of internal switching, polarity handling, and system protection. This makes it ideal for both consumer electronics and industrial applications.
A 2.1 mm DC Power Jack is a common connector used to provide power to various electronic devices. It's a versatile and reliable solution for a wide range of applications, from small portable devices to larger industrial equipment.
Understanding the Basics:
3 Pins: The "3-pin" refers to the number of contacts or terminals on the jack. These pins are typically arranged in a circular or rectangular configuration.
Center Pin: The center pin is usually the positive (+) terminal, while the outer pins are typically the negative (-) and ground terminals.
Barrel Jack: 2.1mm DC Power Jacks are often called "barrel jacks" due to their cylindrical shape.
Key Features and Considerations:
Center Pin Diameter: The diameter of the center pin is crucial for compatibility with the corresponding DC power plug. Common sizes include 2.1 mm, 2.5 mm, and 3.5 mm.
Outer Diameter: The overall diameter of the jack determines the size of the hole needed for panel mounting.
Current Rating: The current rating indicates the maximum amount of current the jack can safely handle. This is important for choosing a jack that can meet the power requirements of your device.
Voltage Rating: The voltage rating specifies the maximum voltage the jack can withstand.
Panel Mount or PCB Mount: These options determine how the jack is mounted: panel mount jacks are designed to be installed on a panel or enclosure, while PCB mount jacks are soldered directly to a printed circuit board.
Locking Mechanism: Some jacks have a locking mechanism to prevent accidental disconnection.
Shielding: Shielded jacks have a metal housing or shielding around the connector, protecting the internal circuitry from electromagnetic interference (EMI) and radio frequency interference (RFI).
The DC Power Jack connector is more than just a power connector—it’s a smart interface for managing power sources. By offering switching capabilities and enhancing protection, it simplifies circuit design and improves device reliability. Whether you're building a portable gadget, a development board, or an industrial device, a panel mount DC Power Jack offers flexibility, convenience, and dependability.
