A right angle DC socket rated at 5.0 amps and 12.0 volts with a panel mount design is a robust and versatile power connector used in a wide range of electrical and electronic devices
This is DC Jack with Locking Nut for Secure Power Connection, it has wide range of options. 2.1 mm DC Power Jacks including straight and right angle PC mount styles, plastic or metal housings, solder terminals and a plenty of center pin size options.
Right Angle DC Socket (5.0A, 12.0V, Panel Mount): A Rugged Power Solution for Compact Designs
A right angle DC socket rated at 5.0 amps and 12.0 volts with a panel mount design is a robust and versatile power connector used in a wide range of electrical and electronic devices. Designed for efficient current delivery and space-saving integration, this type of socket offers reliable power input while maintaining a low profile and easy accessibility. Let’s explore the features, advantages, and applications of this highly functional component.
2.0 mm Center Pin: Ensures compatibility with a wide range of DC power plugs, offering a secure and reliable connection.
5.0 A Current Rating: Provides ample power capacity for various electronic devices, ensuring efficient and reliable operation.
Right Angle Design: Saves space and minimizes clutter by mounting at a 90-degree angle to the surface, ideal for panel mounting.
Panel Mount: Designed for seamless integration into panels or enclosures, offering a professional and secure mounting solution.
Shielded: Features a robust metal housing or shielding to protect the internal circuitry from electromagnetic interference (EMI) and radio frequency interference (RFI). This ensures stable and reliable power delivery, even in noisy environments.
Right Angle Design
The right angle configuration allows the power cable to connect horizontally rather than vertically. This is especially useful in compact enclosures or wall-mounted devices where vertical clearance is limited. The right angle layout also reduces cable strain and helps manage wire routing more efficiently.
Rated for 5.0A, 12.0V
With a current rating of 5.0 amps and a voltage rating of 12.0 volts, this DC socket is suitable for medium-power applications such as small appliances, embedded systems, lighting, automotive accessories, and industrial equipment. These ratings ensure safe and stable power transmission without overheating or electrical noise.
Panel Mount Configuration
Designed to be installed on a device's front or rear panel, this socket is secured in place using a threaded barrel and nut, or in some cases, snap-in or clip mounts. The panel mount design provides a clean and accessible power input point, ideal for products that need to maintain a neat and user-friendly interface.
Barrel Connector Compatibility
These panel mount DC Power Jacks typically support common barrel plug sizes such as 5.5mm outer diameter with 2.1mm or 2.5mm inner pins. Ensuring the correct plug-socket match is essential for maintaining electrical integrity and avoiding loose connections or damage.
Durability and Construction
Most 5.5 x 2.1 mm DC Power Jacks are built with high-quality thermoplastic insulation and corrosion-resistant metal contacts (like nickel-plated brass), ensuring a long operating life even under frequent use. Some versions are also available with weatherproofing or dust protection features for harsh environments.
