Mini Tactile switch with LED

A 6x6mm tactile switch with an integrated red LED is a compact, versatile component widely used in various electronic applications, including module synthesizers, control panels, and other user interface devices. This type of switch combines the tactile feedback of a momentary switch with the visual indication provided by an LED, making it ideal for situations where both physical and visual feedback are necessary.

Key Specifications

Features

1. Integrated LED: Provides a clear visual indication when the switch is activated. The red LED is particularly useful for alert or status indication.

2. Compact Size: The 6x6mm footprint makes it ideal for applications where space is limited.

3. Tactile Feedback: A noticeable click sensation confirms actuation, enhancing user experience.

4. Versatile Mounting Options: Available in both through-hole and surface mount configurations, making it suitable for various PCB designs.

5. Durability: Designed to withstand extensive use, ensuring long-term reliability.

Applications

Module Synthesizers: Used for triggering sounds, navigating menus, or adjusting parameters. The red LED provides a visual cue, helping users see which buttons are active, even in low-light conditions.

Consumer Electronics: Keyboards, remote controls, gaming controllers, and other devices that benefit from tactile and visual feedback.

Industrial Controls: Equipment that requires reliable user input and status indication.

Medical Devices: Interfaces that need both tactile feedback and visual confirmation for safety and usability.

Installation Tips

1. Soldering: Proper soldering techniques are crucial to avoid damaging the LED. For surface mount versions, reflow soldering is typically used.

2. Power Supply: Ensure the LED receives the correct voltage and current to avoid burnout. Typically, a current-limiting resistor is required in the circuit.

3. Testing: After installation, verify both the tactile action and LED functionality to ensure reliable operation.

A 6x6mm tactile switch with a red LED is a practical and efficient choice for many electronic applications. Its combination of tactile feedback and visual indication enhances user experience and interface reliability. When selecting such a switch, consider the specific requirements of your application to ensure optimal performance.
