A through-hole tact switch with an LED is a type of switch that combines a tactile switch for user input with an integrated Light Emitting Diode (LED) for illumination. Here are typical specifications for a through-hole tact switch with an LED:
A through-hole tact switch with an LED is a type of switch that combines a tactile switch for user input with an integrated Light Emitting Diode (LED) for illumination. Here are typical specifications for a through-hole tact switch with an LED:
1. Switch Type: Tactile Switch: The switch is a momentary tactile switch, providing tactile feedback when pressed. It returns to its original state when the force on the button is released.
2. LED Integration: Integrated LED: The switch includes an LED, often positioned beneath or around the switch button. The LED can emit light in various colors, providing visual feedback or illumination.
3. Switch Configuration: SPST (Single-Pole, Single-Throw): This indicates that the switch has a single set of contacts, providing a single on/off function.
4.Switching Action: Normally Open (NO) or Normally Closed (NC): Depending on the design, the switch can be normally open (closed when pressed) or normally closed (open when pressed).
4. Voltage Rating:
LED Voltage: The voltage rating for the LED, specifying the range of voltages at which the LED operates optimally.
Switch Voltage: The voltage rating for the switch contacts, indicating the maximum voltage that can be applied across the contacts.
5. Current Rating:LED Current: The current rating for the LED, indicating the operating current for optimal illumination.
Switch Current: The current rating for the switch contacts, indicating the maximum current that can pass through the contacts.
6. Size and Dimensions:
Through-Hole Design: The switch is designed for through-hole mounting on a printed circuit board (PCB).
7.Termination Style:
Through-Hole Pins: The switch has leads or pins designed for through-hole mounting.
