Toggle switch is a manual operation control switch,it’s design for control the break and connect on the AC or DC current circuit.
Mini ON-ON toggle switches are compact, reliable, and easy-to-use components designed for switching between two circuits or functions. With their small footprint and dependable mechanical action, these switches are widely used in electronics, automation systems, hobbyist kits, and even commercial-grade equipment where space-saving and functionality are key.
The ON-ON configuration means the switch toggles between two active positions — each terminal connects to a different output — allowing users to select between two states without an off position in between. This makes it especially useful for controlling modes, directions, or signal paths in a seamless and intuitive manner.
Most mini ON-ON toggle switches feature a single-pole double-throw (SPDT) or double-pole double-throw (DPDT) design. SPDT switches are commonly used for basic control needs such as toggling between two power sources or switching audio signals. DPDT versions provide dual-channel switching, making them suitable for reversing motors, flipping signal pairs, or other more complex applications.
Durability is a key advantage. Despite their size, quality mini toggle switches often feature robust metal levers, solder lugs or PCB pins, and a solid mechanical design that ensures tens of thousands of reliable cycles. The actuator toggle offers a satisfying tactile feedback, giving users confidence in each operation.
These switches are commonly found in:
Audio gear and instrument effects pedals
DIY electronics and prototyping boards
RC models and robotics
Test equipment and control panels
Small appliances and lighting systems
Installation is simple. Many mini toggle switches can be panel mounted through a standard 6mm-7mm mounting hole, secured with a nut and washer. Wiring is typically done via solder lugs or PCB pins, depending on the model.
Whether you're building a custom control panel, modifying a piece of gear, or designing a compact circuit that needs dependable switching, mini ON-ON toggle switches offer the perfect blend of size, performance, and flexibility.
1. Sub-miniature size will save the PCB board space
2. ON-OFF,ON-OFF-ON,ON/OFF many configurations options
3. Smooth operation mechanism,reliable function
