Toggle switch is a manual operation control switch,it’s design for control the break and connect on the AC or DC current circuit.
The toggle switch is also called as rocker switch,sub-miniature size will save the PCB board occupation space,it’s design for micro current circuit applications.Super antistatic structure,It is composed of carburized bushing and support bracket,Prevent static electric discharge to contact;Locking rod mechanisms are provided as rocker options,6mm diameter bushing for panel sealing installation (threaded optional).
The toggle switch 3 way is a straightforward yet highly useful electrical component widely used in various electronic systems. As the name implies, it features two electrical pins that serve as connection points for the circuit. These pins are typically made of highly conductive materials, such as copper or brass, ensuring reliable electrical contact.
In terms of design, the 3 way on on on toggle switch has a toggle lever that can be manually moved between two positions. When the lever is in one position, the two pins are electrically connected, allowing current to flow through the circuit. When toggled to the other position, the connection is broken, interrupting the current. This simple on - off functionality makes it ideal for basic power control or circuit switching tasks.
The construction of a two - pin toggle switch often includes a durable housing, usually made of plastic or metal. Plastic - housed switches are cost - effective and suitable for general - purpose applications, while metal - housed ones offer enhanced durability and protection, making them suitable for more demanding environments.
Three - pin toggle switches find applications in a wide range of products. In consumer electronics like radios, small fans, and battery - operated toys, they are used to turn the devices on and off. In DIY electronics projects, they provide an easy - to - use way to control the power supply to different circuits. Their simplicity, reliability, and affordability make them a popular choice for both professional engineers and hobbyists looking to create functional electrical setups.
1. Sub-miniature size will save the PCB board space
2. ON-OFF,ON-OFF-ON,ON/OFF many configurations options
3. Smooth operation mechanism,reliable function
